UV Curing Oven
Professional mercury lamp UV curing system with 365nm peak wavelength. PLC touch screen control with adjustable conveying speed for precise curing processes.
Product Description
The UV Curing Oven is an advanced ultraviolet curing system designed for industrial PCB and SMT manufacturing processes. Equipped with high-performance mercury lamps emitting wavelengths from 200-400nm with a main peak at 365nm, it delivers optimal curing energy for UV-sensitive adhesives, coatings, and inks.
Featuring an intuitive PLC touch screen control system, operators can easily adjust parameters and monitor the curing process in real-time. The conveying speed is adjustable from 0.5 to 3.5M/min, allowing precise control over exposure time to match different material requirements.
With a maximum PCB width capacity of 450mm and powerful 1500 cubic meters per hour exhaust system, the UV Curing Oven ensures uniform curing results while maintaining a clean working environment. The bi-directional transmission design offers flexible production line integration.
Technical Highlights
Key specifications that define excellence
Mercury lamp peak:365nm
Chain conveyor with auto width adjustment
Lamp replacement cycle for long service life
Auto Adjustable conveying speed range
Total power of mercury lamp steplessly adjustable
Total power consumption
Key Features
Advanced UV curing technology for superior results
Mercury UV Lamp
High-intensity mercury lamp with 200-400nm wavelength range and 365nm main peak for effective UV curing.
PLC Touch Control
Intuitive PLC touch screen interface for easy parameter adjustment and real-time process monitoring.
Aluminum Alloy Track
Customized hard aluminum alloy track with stainless steel chain for smooth and reliable delivery.
Bi-directional Transmission
Left-right or right-left transmission direction for flexible production line integration.
Adjustable Rail Width
Manual width adjustment to accommodate various PCB sizes up to 450mm maximum width.
Powerful Exhaust
1500 cubic meters per hour exhaust capacity with Φ150mm air outlet for effective ventilation.
Steel Strip Support
Stainless steel wear strip support with 5KG/m evenly distributed track load capacity.
Stepless Adjustment
Power steplessly adjustable for precise control over UV light intensity and curing energy.
Technical Parameter
Complete technical specifications and parameters.
| Item | Specification and description |
|---|---|
| Dimensions | Length 1500mm*1050mm*1540mm (including casters, excluding three colors light) |
| Control method | PLC+touch screen control |
| PCB height | 900±20mm |
| Delivery method | Customized hard and hard aluminum alloy track + stainless steel chain |
| Track length | 1530mm (the inlet and outlet extend 15mm each) |
| Track load | Stainless steel wear strip support 5KG/m evenly distributed |
| Shipping speed | The governor adjusts 0.5-3.5M/min |
| Transmission direction | left-right or right-left |
| Transmission motor power | AC220V 120W |
| PCB width | Maximum width 450mm |
| Rail width adjustment method | Manual adjustment |
| Number of UV tubes | 1 set of light source |
| UV light source power | 5.6KW/pc |
| UV light source type | Mercury lamp, wavelength: 200-400nm; main peak: 365nm; power: steplessly adjustable. |
| Lamp replacement cycle | 800H |
| Equipment ventilation | One 150mm air outlet |
| Exhaust volume requirements | 1500 cubic meters/H |
| PCB board size | W450mm*L450mm |
| PCB board components over-board height | ±100mm |
| Equipment net weight | 410KG |
| Power supply | AC380V 50Hz three-phase five-wire system |
| Total power | 7KW |
